Athearn Genesis # ATHG63996 HO SDP40F w/DCC & Sound, BNSF #6962
EMD SDP40F WILL POSESS THE FOLLOWING FEATURES:
All lighting feature LEDs
Rubber MU hoses for durability
Better than brass detail™
DCC+Sound models contain full-feature Tsunami2 sound decoder with EMD 645E3 prime mover sounds by SoundTraxx
Genesis 2.0 model features
Illuminated ground lights
Illuminated Numberboards
AMTRAK FEATURES:
Units from Amtrak’s second order, featuring flat nose
Steam line access door snow plow pilot
Low profile dustbin, exhaust silencer, fan housings
Dual steam generators
As delivered fuel/water tank
Illuminated gyra/big hole signal lights
Illuminated cab class lights
Roof mounted sinclair antenna and cab vent
Official Amtrak licensed product
PHASE III FEATURES:
Position and size of Amtrak lettering varies per road number
Repainted Phase III
#622, 626:
“Small” ice breakers, ACI labels, no rear numbers, SL4T horn
#631, 634:
No ice breakers, small blue rear numbers, no ACI labels, early K5 horn
PHASE I FEATURES:
Leslie S4T air horn (unique to these engines)
First time Icicle breaker bars front & rear
Phase I paint
#583, #586:
Small blue road numbers on rear of body
#625, #629:
No rear numbers
BNSF FEATURES:
Former ATSF rebuilt SDF40-2 body
#6962 Roof mounted prime air conditioner removed
Other details same as ATSF units
MAERSK FEATURES:
ATSF rebuilt steam line access door snow plow pilot
ATSF rebuilt “Notch Nose” front step wells/handrails
Standard profile fan housings
Steam generator removed rear hood
ATSF rebuilt fuel tank
Flat nose variant
Cab mounted headlight
Nathan K3 horn on angled bracket
Antenna plane mounted sinclair antenna
Roof mounted prime air conditioner removed
On August 15, 2002, to commemorate the opening of the world’s largest container terminal (Pier 400 in Los Angeles), Maersk Sealand had one BNSF and one NS locomotive painted in their blue and silver scheme. The locomotives were loaned to Maersk for promotional events but retained their respective owner’s reporting marks. SDF40-2 6976 was the locomotive selected as the BNSF representative.
ATSF FEATURES:
ATSF rebuilt steam line access door snow plow pilot
ATSF rebuilt “Notch Nose” front step wells/handrails
Standard profile fan housings
Steam generator removed from rear hood
ATSF rebuilt fuel tank
Flat nose variant
Antenna plane mounted sinclair antenna
Roof mounted prime air conditioner
#5251:
Rebuilt nose with yellow patches around the “Notch Nose” and stepwell per prototype rework
Recessed nose mounted headlight
Hood mounted Leslie S3L air horn on bracket
#5252:
Cab mounted headlight
Cab mounted Blue Nathan K3 air horn on bracket
#5258:
Recessed nose mounted headlight
Hood mounted Yellow Nathan K3 air horn
#5262:
Recessed nose mounted headlight
Hood mounted Blue Nathan K3 air horn on bracket
“Santa Fe” herald located further back on hood
LOCOMOTIVE FEATURES:
Front and rear 3-hose M.U. hose clusters with silver ends
Front and rear trainline hoses
Illuminated number boards
Illuminated classlights
Illuminated ground lights (above the trucks aligned to cab side windows)
Non-skid end walks
Fine-scale end handrails for scale appearance
Detailed and painted cab interior with control stand
4,500 gallon split fuel/water or rebuilt fuel only tank
HTC sideframes with high brake cylinders and air lines
Flush mounted portal window glass
Factory applied wire grab irons and lift rings
Minimum radius: 18”
Recommended radius: 22”
GENESIS® DIESEL LOCOMOTIVE FEATURES:
Fully-assembled and ready-to-run
DCC-ready features Quick Plug™ plug-and-play technology with 21-pin connector
Scaled from prototype resources including drawings, field measurements, photographs, and more
Accurately painted and printed paint schemes
Coupler cut levers
MU hoses
Trainline hose
See through cab windows
Full cab interior
Walkway tread
Fine-scale Celcon handrails for scale appearance (rear only on Amtrak models)
Windshield wipers
Lift rings
Wire grab irons
Detailed fuel tank with fuel fillers, fuel gauges, breather pipes, and retention tanks
Sander lines
McHenry scale knuckle couplers - Kadee compatible
Genesis driveline with 5-pole skew wound motor, precision machined flywheels, and multi-link drivetrain for trouble free operation
All-wheel drive with precision gears for smooth and quiet operation
All-wheel electrical pickup provides reliable current flow
Wheels with RP25 contours operate on all popular brands of track
Scale brightness LED lighting (adjustable via CV changes)
Bidirectional constant lighting so headlight brightness remains constant
Heavy die-cast frame for greater traction and more pulling power
Packaging securely holds for the model for safe storage
Replacement parts available
GENESIS 2.0 FEATURES:
By integrating and pioneering some of the latest model advancements in the industry, Athearn is redefining model fidelity with Genesis 2.0.
Illuminated number boards
Illuminated ground lights
SOUND EQUIPPED MODELS FEATURE:
Onboard DCC decoder with SoundTraxx Tsunami2 sound
Twin 28mm speakers
Sound units operate in both DC and DCC
Full DCC functions available when operated in DCC mode
Engine, horn, and bell sounds work in DC
All functions NMRA compatible in DCC mode
Excellent Slow speed control
Operating lighting functions with F5 and/or F6
Program a multiple unit (MU) lashup with lead unit only horn, bell, and lights
Many functions can be altered via Configuration Value (CV) changes
CV chart included
PROTOTYPE INFO:
Formed in 1971, Amtrak took over operation of most of America’s passenger trains with an assortment of old locomotives, primarily decades-old E-units. The carrier worked with General Motors Electro-Motive Division to design new passenger locomotives. The result was the SDP40F. Built by EMD from 1973–1974 for Amtrak and for a brief time they formed the backbone of Amtrak’s long-distance passenger fleet. With 150 built, the SDP40F became the “face” of Amtrak in the mid-1970s as they were found on the head ends of passenger trains from San Diego to Washington DC and from Seattle to Miami. Several were rebuilt and found a second life with the Atchison, Topeka and Santa Fe Railway in freight service.
The design of the SDP40F was based on the EMD FP45 passenger locomotive. Both shared the EMD 645E3 diesel engine, although the SDP40F had 16 cylinders instead of 20. The space saved from the smaller prime mover was given over to increased water capacity. The SDP40F had an underbody tank split between water and diesel fuel, carrying 2,000 gallons of water and 2,500 gallons of diesel. A second 1,500 gallon water tank sat in the carbody, forward of the steam generators which produced the steam needed for supplying heat (and sometimes cooling) and hot water for the train.
Eventually, the SDP40F was phased out as all-electric cars, such as the Amfleet, displaced the old steam heat rolling stock. While the SDP40F was designed with conversion to head-end power (HEP) in mind, the bad press they received, cost to upgrade and overhaul the units, and Amtrak’s satisfaction with the versatility of the HEP-equipped F40PH ultimately doomed the SDP40F. Amtrak was able to trade in the SDP40Fs to EMD as more F40PH units were acquired in the late 1970s. The last SDP40F was retired from Amtrak in the early 1980s.
In 1984, Santa Fe Railway traded lower-power locomotives to Amtrak for 18 SDP40Fs, horsepower-for-horsepower. The SDP40Fs were reconditioned in the railroad’s San Bernardino, California shops to the designation SDF40-2 for use as freight locomotives. Santa Fe replaced the hollow HTC bolsters with conventional HTC bolsters, converted the below-frame combination fuel/water tank to an all-fuel tank, removed the above-frame water tanks (replacing these with concrete ballast) and used the engines for nearly 15 years. They were also given front steps and platforms. Their noses were notched after a second maintenance shop visit in order to improve boarding access. In exchange, Amtrak received 43 smaller locomotives for use in switching service.
This page is based on the copyrighted Wikipedia article "EMD SDP40F"; it is used under the Creative Commons Attribution-ShareAlike 3.0 Unported License (CC-BY-SA). You may redistribute it, verbatim or modified, providing that you comply with the terms of the CC-BY-SA.
Specifications
DCC: Equipped
SOUND: Tsunami2
PROTOTYPE MANUFACTURER: EMD
Axles: 6
LIGHTED: LED Lighting
Minimum Age Recommendation: 14 years
Is Assembly Required: No
