Tamiya #58707 1/10 XV-02 PRO Chassis Kit
Featured Components
Drivetrain: Full ball bearings .Aluminum propeller shafts (front/rear) Oil-filled gear differentials (front/rear, two 39T and one 40T included) Universal drive shafts (front/rear)
Suspension: Aluminum long dampers (front/rear, with blue caps) 6-degree caster blocks .Turnbuckle shaft upper arms
Chassis: Front bumper with skid angle .Polycarbonate chassis cover .Aluminum servo mount .Hi-torque servo saver
Specifications
Length: 368mm, width: 180mm .Wheelbase: 257mm .Bathtub frame .Front-midship motor, shaft-driven 4WD .Oil-filled gear differentials .3-piece steering tie-rod .4-wheel independent double wishbone suspension .Long oil dampers with aluminum cylinders .Gear ratio (with kit-standard 19T pinion) = 9.58:1 (14 ratios between 10.71:1 and 6.28:1 possible with separately sold pinions) .Hobbywing Electronic speed controller
Separately Required Items
Body .Type 540 motor ,2-channel R/C system ,R6/AA/UM3 batteries for transmitter ,Battery pack & charger
This shaft-driven 4WD chassis kit features a front midship motor and transmits power from the spur gear in the center via identical length front and rear long propeller shafts, which allows running on surfaces from on-road to flat dirt. 39T differential gears front and rear, and one setup option 40T differential gear are included, facilitating changes to drive balance. It features optimum balance and a slim chassis, plus 4-wheel independent double wishbone suspension with aluminum-cylinder long oil dampers.
• Required to complete: Body, battery pack, motor, ESC, 2-channel radio and servo.
