Tamiya #47392 1/10 1977 Tyrell P34 6 Wheeler

SKU:
4950344473922
$395.00
(No reviews yet) Write a Review
Current Stock:

Out of stock

Out of Stock

Tamiya #47392 1/10 1977 Tyrell P34 6 Wheeler

Six of the Best
The Tyrrell P34 featured a revolutionary design with four front wheels, which made its debut during the 1976 season. The following year, First National City Bank became the team's main sponsor and the cars were given a blue and white livery and more aerodynamic full-body fairing. However, the cars reverted to the previous year's semi-fairing for the Monaco Grand Prix. This special edition R/C model assembly kit depicts the 1977 Monaco GP Tyrrell P34, with the polycarbonate body, engine, rear wing and more pre-painted, plus complex sections pre-cut. Simply paint the driver and apply stickers to complete the body!



Special 6-Wheeled F103 Chassis
The high performance direct drive 2WD chassis utilizes a semi double deck frame with 1.5mm thick upper and 2.5mm thick lower FRP plates. Kingpin coil spring 4-wheel independent front suspension consists of the one-piece lower arm and individual left/right upper arms. One servo controls the steering of all four front wheels. The rear suspension features a rigid T-bar with a TRF damper and low-friction pads. The spur gear has a built-in ball diff for limited slip effect. Grippy sponge tires masterfully harness the power provided by the torque-tuned motor.

Length: 430mm, Width: 200mm, Height: 108mm

Tread: 140mm (Front), 155mm (Rear)

Tire Width/Diameter: 23/44mm (Front), 45/64mm (Rear)

FRP Semi-Double Deck Frame

Direct Drive RWD

Ball Differential

2-Piece Steering Tie-Rod

Suspension: Front King Pin Coil Spring, Rear T-Bar Rigid

Gear Ratio = 4.5:1 (using 14T pinion/63T spur combination)

Torque-Tuned Motor

Electronic Speed Controller (ESC) is sold separately.


Separately Required Items

2-Channel R/C System w/ESC

R6/AA/UM3 batteries for transmitter

Battery Pack & Charger
