Surpass # Waterproof Combo M2430 Brushless Motor W/ M35A ESC 2S 5800KV
M35A ESC Feature:
1. Water-proof and dust-proof for all-weather races; (Note: please uninstall the cooling fan before using this ESC in water; Clean and dry it soon after the use for avoiding the connectors get rusty.)
2. Specially designed for RC car with excellent start-up, acceleration and linearity features.
3.Compatible with sensorless brushless motor.
4. The strong resistant current capability,excellent heat dissipation.
5. Multiple protection features: Low voltage cut-off protection for lithium or nickel battery/Throttle signal loss protection /Motor blocked protection.
6. Low voltage cut-off protection the motor emits"Beep-Beep"and the LED flashes.
7.Built-in switch-mode BEC 5V/2A for usage with high torque and high voltage servos.
8. Easily programmed and compatible with pocket-sized program card
Specification:
Model:M35A
Cont.Current/ Burst Current: 35A/120A.
Motor Type: Sensorless Brushless Motor
For 2S Lipo or 6 cells NiMH:
1.on-road:28XX-size or smaller motor with the KV<6000
2.Off-road /Buggy/Monster:28XX-size or smaller motor with the KV<4000
For 3S Lipo or 9 cells NiMH:
1.On-road:28XX-size or smaller motor with the KV<4000
2.Off-road /Buggy/Monster:28XX-size or smaller motor with the KV<3000
Suitable Car: 1/16,1/14 car
Resistance:0.0021ohm
Battery: 2~3 cells Lipo, 4~9 cells NiMH
BEC Output: 5V/2A(Analog mode)
Connet to motor:3.5mm
Dimension:40x29x29.2mm
Weight:47g
